Greaves Power Generators

Genset Rating (kVA / kW): 2.5 / 2.5

Genset Model: GPA II-2.5

No of Phases & PF: 1 / 3

Voltage Range (Volts): 230/415

Current (@ 0.8 PF) in Amps: 10.9/3. ?

 Genset Rating (kVA / kW): 3.5 /3.5

Genset Model: GPA II-3.5

No of Phases & PF: 1 / 3

Voltage Range (Volts): 230/415

Current (@ 0.8 PF) in Amps: 15.2/4.9 ?

Genset Rating (kVA / kW): 5 / 4

Genset Model: GPA II-5

No of Phases & PF: 1 / 3

Voltage Range (Volts): 230/415

Current (@ 0.8 PF) in Amps: 21.7/6.9

Greaves Power 50 kVA AC Three Phase Diesel Generator Set, Model: GPW II-PII-50

Product Specification
Power (KVA) 50 KVA
Output Type AC Three Phase
Brand Greaves
Engine Power 80.1 BHP
Engine rating or Max Power at rated RPM 59 KW
Engine Model 3G11TAG25
Engine Type TCAC
Displacement 3.66 L
Bore and Stroke 108 X 133 mm
Compression Ratio 16.8
Rated RPM 1500
Over Speed Trip 1650 rpm
DG Set Dimension 2500 x 1150 x 1535 mm
Integral Fuel Tank 150 Ltr
Weight 1210 Kg
Phase 3 Phase
Genset Manufacturer Greaves Power
Genset Rating Prime Power
Genset Output 50 KVA – 50 KW
Genset Model GPW II-PII-50

Greaves Power 250 kVA Air Cooled Diesel Generator Set, Dimension: 4500 x 1800 x 2200 mm

Product Specification
Brand Greaves Power
Dimension 4500 x 1800 x 2200 mm
Weight 4050 kg
Genset Output (KVA / KW) 250 / 200
Bore & Stroke (mm) 128 X 130
Compression Ratio 16.8
Rated Speed 1500 RPM
Genset Rating Prime Power
Genset Model GPW II-PII-250
Engine Rating or Max Power at Rated RPM in KW BHP 227 (309)
Engine Model D3V6TAG21
Engine Type TCAC
No of Cylinders 6
Cylinder Arrangement V- Type
Displacement 10.03 L
Governor Type Electronic
Class of Governing G3
Frequency regulation No load to full load Isochronous
Over Speed Trip 1650 RPM
Maximum Allowable Back Pressure 5.1 +/- 0.5 kPa

15 kVA Greaves Power Diesel Generator, Frequency: 50 Hz

Product Specification
Frequency 50Hz
Number of Cylinder 2
Brand Greaves Power
Compression Ratio 17.5
Displacement 1.56 L
Engine Model G-15-II
Engine Type Natural Aspirated
Genset Output 15 / 12 KVA per KW
Maximum Allowable Back Pressure 4 kPa
Power 15 kVA
Rated Rpm 1500
Bore And Stroke 95X110 mm
Genset Rating Prime Power
Insulation Class H
Dimension 1800 x 950 x 1335 mm
Weight 740 kg
Cykinder Arrangement Inline
Voltage Regulator Solid State
Temperature Rise 125 Deg. C (Class H)
One step load acceptance 100% of rating
Bearing 1,Sealed (Quantity, Type)
Coupling Flexible Disc, Close Coupled
Voltage Regulation 2 Phase sensing, +/-1% (No load to full load)
Unbalance load capability 25% of rated current
Type or Class of Governing Mechanical/G2
Exciter Type Brushless
Water Pump Type Engine Mounted
Radiator System Capacity 7.5 Ltr (including engine)
Voltage 380-440V
Alternator Type 4 Pole , Rotating field
Engine Rating or Max Power at rated RPM in KW BHP 15.9 (21.6)

30 kVA Greaves Generator

30 kVA Greaves Generator Technical Specification:
DG Set Model Rating (kVA) Canopy Size (LxWxH) Battery (Ah) Starting System Weight (Kg) Fuel Tank Capacity (Ltrs) Engine Model Engine Make Engine Power (bhp) Rated Speed No. of Cylinders Bore (mm)
GPWII-PII-30 30 1990x950x1335 88 12V DC 1180 75 G-30-II Greaves 42 1500 3 91
Stroke (mm) Total Displacement (cc) Lube oil Sump Capacity (Ltrs) Compression Ratio Aspiration Cooling System FIP Emission Norms Alternator Type Frequency Voltage
110 2140 6.5 17.5 TCAC Water / Coolant Mechanical CPCB-II Complaint Crompton Greaves Brushless, H Class Insulation 50 230/415
